In the process of usually operating the cone crusher, in addition to understanding its operation method and the use of each part, you also need to understand some common fault solutions of the cone crusher. The following Zhongxin briefly introduces the solution of the lower tank fault for you.

    1. When the cone crusher is working, it is found that the oil temperature exceeds 55 ℃, but the oil pressure is normal. The cause of this problem is mainly due to the abnormality of the eccentric shaft. The solution is to s the equipment and continue to run, then check the straight bush And taper bushings, find out the cause and remove it before running.

    2. When it is found that the oil temperature will rise at the same time as the oil pressure rises, the main reason for this problem is that the oil pipe or the cone crusher has an internal oil blockage. The solution is also very simple, that is S the operation of the equipment and find the blockage and clear it.

    3. The oil temperature from the cooler still exceeds the standard value. There are three main reasons for this. One is that there is no cooling water, the second is that the temperature of the cooling water is too high, and the third is that the cooler is clogged. The solution is also very simple. Treat the symptoms and give cooling water; check whether the water pressure is too low, and increase the pressure as much as possible, check the cooling water temperature; clean the cooler.

    4. The indicator does not flow oil, but the oil pressure is displayed. The main reason is that the oil switch is not set properly or there is a problem with the oil pump. S the equipment in time, find the problem and then deal with it.

    5. There is water in the oil, and the amount of oil in the oil tank increases. The main reason is that the water pressure in the cooler is higher than the oil pressure. At this time, it is enough to make the water pressure in the cooler lower than the oil pressure by 0.005MPa.
